Colored Resin : DRx-RJE
29/06/2011 V5.0
5
DomiLEDTM • Colored Resin : DRx-RJE Package Outlines
Material
Material
Lead-frame
Package
Encapsulant
Soldering Leads
Cu Alloy With Ag Plating
High Temperature Resistant Plastic, PPA
Epoxy
Sn-Sn Plating
DOMINANT
Opto Technologies
Innovating Illumination
TM
