background image
SPS-43-48H-CP-RDF
DS-5980 Rev 01 2013-08-23
EEPROM Memory Map
Table 9 - I2C A0h Address
DEC
Addr.
HEX
Addr.
Field Size
(bytes)
Name
Default Value
Description
0
00
1
Identifier
03h
Module soldered to
motherboard
1
01
1
Extended Identifier
04h
Function defined by serial
ID
2
02
1
Connector
01h
SC Receptacle
3
03
8
Transceiver
000000 00 00 0000 00h
Transceiver Code Field, not
applicable
11
0B
1
Encoding
03h
NRZ encoding
12
0C
1
Nominal Bit Rate in 100
MBps
19h
2488.32 Mbps
13
0D
1
Reserved
00h
Reserved
14
0E
1
Length (9µ,km) in km
14h
20km
15
0F
1
Length (9µ,m) in 100m
C8h
20km
16
10
1
Length (50µ) in 10m
00h
Not Supported
17
11
1
Length (62.5µ) in 10m
00h
Not Supported
18
12
1
Length (Copper) in m
00h
Not Supported
19
13
1
Reserved
00h
Reserved
20
14
16
Vendor Name (ASCII)
"SOURCEPHOTONS"
Vendor Name (ASCII)
36
24
1
Reserved
00h
Reserved
37
25
3
Vender IEEE Company
ID
00 06 B5h
Source Photonics IEEE ID
40
28
16
Vendor Part Number
(ASCII)
"SPS4348HCPRDF"
Vendor Part Number
(ASCII)
56
38
4
Vendor Rev (ASCII)
31 20 20 20
Revision 01
60
3C
2
Laser Wavelength in nm
05 D2h
1490nm Tx Wavelength
62
3E
1
Reserved
00h
Reserved
63
3F
1
Check Code for Base ID
Fields
xxh
Checksum from byte 0‐62
64
40
2
Options
00 1Ch
TX_DIS, TX_Fault, SD
66
42
1
Upper Bit Rate Margin
in %
00h
BR, Max not specified
67
43
1
Lower Bit Rate Margin
in %
00h
BR, Min not specified
