10-R0126PA015SC-M628F40
10-RZ126PA015SC-M628F41
Figure 29
IGBT
Reverse bias safe operating area
IC = f(VCE)
At
Tj =
Tjmax-25
ºC
Uccminus=Uccplus
Switching mode :
3 level switching
Figure 1
Thermistor
Typical NTC characteristic
as a function of temperature
RT = f(T)
Thermistor
NTC-typical temperature characteristic
0
1000
2000
3000
4000
5000
25
50
75
100
125
T (°C)
0
5
10
15
20
25
30
35
0
200
400
600
800
1000
1200
1400
V CE (V)
IC MAX
11
Revision: 2
Copyright by Vincotech
