background image
INCHANGE Semiconductor
isc Product Specification
isc website：www.iscsemi.cn
isc & iscsemi is registered trademark
2
isc Silicon NPN Power Transistor
2SC5949
ELECTRICAL CHARACTERISTICS
TC=25℃ unless otherwise specified
SYMBOL
PARAMETER
CONDITIONS
MIN
TYP.
MAX
UNIT
V(BR)CEO
Collector-Emitter Breakdown Voltage
IC= 50mA ; IB= 0
200
V
VCE(sat)
Collector-Emitter Saturation Voltage
IC= 10A; IB= 1A
3.0
V
VBE(on)
Base-Emitter On Voltage
IC= 8A ; VCE= 5V
1.5
V
ICBO
Collector Cutoff Current
VCB= 200V ; IE= 0
5
μA
IEBO
Emitter Cutoff Current
VEB= 5V; IC= 0
5
μA
hFE-1
DC Current Gain
IC= 1A ; VCE= 5V
55
160
hFE-2
DC Current Gain
IC= 8A ; VCE= 5V
35
COB
Output Capacitance
IE=0 ; VCB= 10V;f= 1.0MHz
470
pF
fT
Current-Gain—Bandwidth Product
IC=1A ; VCE= 5V
25
MHz
hFE-1 Classifications
R
O
55-110
80-160
