Page 1 of 2

Revised: 19-Dec-13

SMD

SMD

SMD

SMD Power Inductor

Power Inductor

Power Inductor

Power Inductor

CDMC104

Description

• Metal compound molding type construction.

• Magnetically shielded.

• L

×W×H: 11.5×10.2×4.0 mm Max.

• Product weight:2.5 g (Ref.)

• Moisture Sensitivity Level: 1

• RoHS compliance.

• Halogen Free available.

Environmental Data

• Operating temperature range: -40

℃～+125℃

(including coil’s self temperature rise)

• Storage temperature range: -40

℃～+85℃

• Solder reflow temperature: 260

℃ peak.

Packaging

• Carrier tape and reel packaging.

• 13.0”diameter reel

• 500pcs per reel

Applications

• Ideally used in low voltage-high current

laptop PC & sever power supply.

Halogen

Free

RoHS

Dimension - [mm]

Land pattern and Schematics - [mm]

Electrical Characteristics

※1. Measuring condition: at 1MHz.

※2. Saturation current: The value of D.C. current when the inductance decreases to 80% of it’s nominal value.

※3. Temperature rise current: The value of D.C. current when the temperature rise is △t＝40℃(Ta＝20℃).

:Electrode

②

①

21.0

21.0

22.0

1.48

±10％

0.56

±20％

R56M

CDMC104NP-R56M

25.0

27.0

28.0

1.10

±10％

0.36

±20％

R36M

CDMC104NP-R36M

(at 125

℃)

(at 20

℃)

Temperature

rise current

(A)

※3

D.C. Saturation current

(A)

※2

D.C.R.

［Within］

(at 20

℃)

(m

Ω)

Inductance

［Within］

(

μH)

※1

Stamp

Part No.
