ASMCI-0603

ELECTRICAL SPECIFICATIONS:

RoHS

Compliant

SMD Multilayer Chip Inductor for Choke

FEATURES:

APPLICATIONS:

1.60 x 0.8 x 0.8mm

Pb

ABRACON IS

ISO 9001 / QS 9000

CERTIFIED

ABRACON IS

CERTIFIED

ISO 9001:2008

30332Esperanza, Rancho Santa Margarita, California 9268

Revised: 02.08.13

Visit

Operating Temperature: -40˚C to +85˚C

Storage Temperature: -10˚C to +40˚C, 70% RH max

• Monolithic structure designed for high reliability

• Excellent solderability and heat resistance

• Magnetic shield designed to eliminate cross coupling

• High DC current and low DCR

Choke circuits in DC power line for PC, mobile phones,

digital cameras, camcorder, and music players.

Part Number

ASMCI-0603-

Inductance Code

Inductance

Tolerance

DCR

SRF Min.

Max. Rated Current

Units

μH

%

Ω ± 30%

MHz

mA

Symbol

L

M=±20%,

N=±30%

DCR

SRF

Ir

ASMCI-0603-R10

0.1

M, N

0.14

240

700

ASMCI-0603-R22

0.22

M, N

0.27

150

550

ASMCI-0603-R47

0.47

M, N

0.42

105

400

ASMCI-0603-1R0

1.0

M, N

0.20

75

190

ASMCI-0603-2R2

2.2

M, N

0.40

50

140

ASMCI-0603-4R7

4.7

M, N

0.60

35

100

ASMCI-0603-100

10

M, N

0.90

20

50

Test Conditions

b. Relative Humidity: 65%±20%

c. Air Pressure: 86KPa to 106KPa

Inductance (L): High Accuracy RF Impedance/Material Analyzer-HP4291B+HP16192A or Equivalent,

1MHz, -20dBm or 50mV.

Direct Current Resistance (DCR): High Accuracy Milliohmeter-HP4338B or Equivalent

Self-Resonant Frequency (SRF): High Accuracy RF Impedance/Material Analyzer

HP4291B+HP16192A or Equivalent, -20dBm or 50mV.

Rated current (Ir): HP6632B system DC power supply, HP4291B+HP16192A+HP16200A or equivalent.

Definition of Rated Current (Ir): Ir is the value of DC current as inductance L (μH) decreased just 50%

against initial value.
