2 / 3 page  Designed and Manufactured in Germany Designed and Manufactured in Germany AXPLT2500 Rev.1 www.axtal.com Roemerring 9 Drawing D0 fon: +49 (6261) 939834 D-74821 Mosbach Page 2(3) fax: +49 (6261) 939836 Germany E-mail: info@axtal.com GmbH & Co. KG Ordering Code Model Input Frequency [MHz] Output Frequency [GHz] Revision AXPLT2500 100.000 6.500 Rev.1 Example: AXPLT2500-100.000-6.500_Rev.1 Enclosure drawing Pin connections: Pin # Symbol Function 1 VS Supply Voltage 2 GND Ground 3 LD Lock Detect Output SMA1 RF OUT RF Output SMA2 FREF Reference Frequency Input |
|
|
