background image
Product description
Designed to UL 248 and UL 248-14, the
Bussmann TCP70 Series of
telecommunication fuses withstand the
wide variations in application environments
while delivering reliable circuit protection.
The fuses have breaking characteristics
similar to a circuit breaker while providing a
much more economical solution.
• Halogen free, lead free, RoHS compliant
• Special design telecom circuit protection
devices
• High inrush current withstanding
capability reduces nuisance openings
• Fuseclip assembly method
• Rugged ceramic construction
• Excellent environmental integrity
• One time positive disconnect
Agency information
• cURus Recognized Guide JDXY2, JDXY8,
File E19180
Part number system/ordering
BK1/
TCP70-
5
-R
• BK1/ = 1000 fuses packed in a cardboard carton
• TCP70- = Fuse series
• 5 = Amp rating
• -R = RoHS compliant
Applications
• Telecommunication DC voltage circuits
Bussmann TCP70 Series
70Vdc Telecom fuses
Technical Data 10250
Effective June 2014
Bussmann is now
part of Eaton
Same great
products plus
even more.
The Bussmann brand of
circuit protection products
(formerly of the
Bussmann Division of
Cooper Industries) is now
part of Eaton’s Electrical
Group, Electronics
Division.
HALOGEN
HF
FREE
Pb
