Product description

Designed to UL 248 and UL 248-14, the

Bussmann TCP70 Series of

telecommunication fuses withstand the

wide variations in application environments

while delivering reliable circuit protection.

The fuses have breaking characteristics

similar to a circuit breaker while providing a

much more economical solution.

• Halogen free, lead free, RoHS compliant

• Special design telecom circuit protection

devices

• High inrush current withstanding

capability reduces nuisance openings

• Fuseclip assembly method

• Rugged ceramic construction

• Excellent environmental integrity

• One time positive disconnect

Agency information

• cURus Recognized Guide JDXY2, JDXY8,

File E19180

Part number system/ordering

BK1/

TCP70-

5

-R

• BK1/ = 1000 fuses packed in a cardboard carton

• TCP70- = Fuse series

• 5 = Amp rating

• -R = RoHS compliant

Applications

• Telecommunication DC voltage circuits

Bussmann TCP70 Series

70Vdc Telecom fuses

Technical Data 10250

Effective June 2014

Bussmann is now

part of Eaton

Same great

products plus

even more.

The Bussmann brand of

circuit protection products

(formerly of the

Bussmann Division of

Cooper Industries) is now

part of Eaton’s Electrical

Group, Electronics

Division.

HALOGEN

HF

FREE

Pb
