 3 / 5 page
background image
LM39102
Preliminary
CMOS IC
UNISONICTECHNOLOGIESCO.,LTD
3 of 5
www.unisonic.com.tw
QW-R102-060.c
ABSOLUTE MAXIMUM RATING
PARAMETER
SYMBOL
RATINGS
UNIT
Supply Voltage
VIN
18V
V
Enable Voltage
VEN
+20
V
Junction Temperature
TJ
-40 ~ +125
°C
Storage Temperature
TSTG
-65 ~ +150
°C
Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
OPERATING RATINGS (Note 1)
PARAMETER
SYMBOL
RATINGS
UNIT
Supply Voltage
VIN
+2.25 ~ +16
V
Enable Voltage
VEN
+16
V
Maximum Power Dissipation
PD
Note 2
Notes: 1. The device is not guaranteed to function outside its operating rating.
2. PD(max)=(TJ(max)-TA)+ θJA, where θJA -junction-to-ambient thermal resistance.
THERMAL DATA
PARAMETER
SYMBOL
RATINGS
UNIT
SOP-8
50
°C/W
Junction to Case
HSOP-8
θJC
45
°C/W



Html Pages

1 2 3 4 5


Datasheet Download

Go To PDF Page


Link URL
