background image
INCHANGE Semiconductor
isc website：www.iscsemi.cn
isc & iscsemi is registered trademark
2
isc Silicon NPN RF Transistor
2SC4591
ELECTRICAL CHARACTERISTICS
TC=25℃ unless otherwise specified
SYMBOL
PARAMETER
CONDITIONS
MIN
TYP.
MAX
UNIT
V(BR)CBO
Collector-Base Breakdown Voltage
IC= 10μA ; IE= 0
15
V
ICBO
Collector Cutoff Current
VCB= 12V; IE= 0
1.0
μ
A
ICEO
Collector Cutoff Current
VCE= 9V; RBE= ∞
1.0
mA
IEBO
Emitter Cutoff Current
VEB= 1.5V; IC= 0
10
μ
A
hFE
DC Current Gain
IC= 20mA ; VCE= 5V
40
250
fT
Current-Gain—Bandwidth Product
IC= 20mA ; VCE= 5V
6.5
9.0
GHz
COB
Output Capacitance
IE= 0 ; VCB= 5V; f= 1MHz
0.8
1.5
pF
PG
Power Gain
IC= 20mA ; VCE= 5V; f= 900MHz
9.5
12.5
dB
NF
Noise Figure
IC= 5mA ; VCE= 5V; f= 900MHz
1.2
2.5
dB
