background image
UNISONIC TECHNOLOGIES CO., LTD
U74LVC3G34
CMOS IC
www.unisonic.com.tw
1 of 5
Copyright © 2015 Unisonic Technologies Co., Ltd
QW-R126-025.A
SINGLE BUFFER GATE
DESCRIPTION
The U74LVC3G34 is a triple buffer gate which provides the
Boolean function Y = A.
The U74LVC3G34 inputs can be driven from either 3.3 V or 5 V
devices.
The U74LVC3G34 IOFF circuitry disables the output, preventing
a damaging backflow current through the device when it is powered
down.
FEATURES
* Wide supply voltage range from 1.65V to 5.5V
* Inputs accept voltages up to 5.5V
* IOFF supports partial-power-down mode
* Low static power consumption; ICC=10μA (Max.)
SOP-8
ORDERING INFORMATION
Ordering Number
Package
Packing
U74LVC3G34G-S08-R
SOP-8
Tape Reel
MARKING
