AD8220
Rev. B | Page 17 of 28
XXX
4µs/DIV
20mV/DIV
Figure 47 Small Signal Pulse Response, G = 100, RLOAD = 2 kΩ, CLOAD = 100 pF,
VS = ±15 V, VREF =0 V
XXX
20mV/DIV
40µs/DIV
Figure 48. Small Signal Pulse Response, G = 1000, RLOAD = 2 kΩ,
CLOAD = 100 pF, VS = ±15 V, VREF = 0 V
XXX
4µs/DIV
20mV/DIV
Figure 49. Small Signal Pulse Response, G = 1, RLOAD = 2 kΩ, CLOAD = 100 pF,
VS = 5 V, VREF = 2.5 V
XXX
4µs/DIV
20mV/DIV
Figure 50. Small Signal Pulse Response, G = 10, RLOAD = 2 kΩ, CLOAD = 100 pF,
VS = 5 V, VREF = 2.5 V
XXX
4µs/DIV
20mV/DIV
Figure 51. Small Signal Pulse Response, G = 100, RLOAD = 2 kΩ, CLOAD = 100 pF,
VS = 5 V, VREF = 2.5 V
XXX
40µs/DIV
20mV/DIV
Figure 52. Small Signal Pulse Response, G = 1000, RLOAD = 2 kΩ,
CLOAD = 100 pF, VS = 5 V, VREF = 2.5 V
