November 14, 2016

ZSC31015 Datasheet

3.7.

Reading EEPROM Contents

The contents of the entire EEPROM memory can be read out using the Read EEPROM command (00HEX). This

command causes the ZSC31015

to output consecutive bytes on the ZACwire™. After each transmission, the

EEPROM contents are shifted by 8 bits. The bit order of these bytes is given in Table 3.11.

Table 3.11 EEPROM Read Order

Bit 7

Bit 6

Bit 5

Bit 4

Bit 3

Bit 2

Bit 1

Bit 0

Byte 1

Offset_B[7:0]

Byte 2

Gain_T[1:0]

Offset_B[13:8]

Byte 3

Offset_T[1:0]

Gain_T[7:2]

Byte 4

TSETL[1:0]

Offset_T[7:2]

Byte 5

Tcg[2:0]

TSETL[6:2]

Byte 6

Tco[2:0]

Tcg[7:3]

Byte 7

Tc_cfg[2:0]

Tco[7:3]

Byte 8

SOT[7:0]

Byte 9

Lock[0]

Diag_cfg[2:0]

SOT_cfg[3:0]

Byte 10

Up_Clip_Lim[5:0]

Lock[2 :1]

Byte 11

Low_Clip_Lim[6:0]

Up_Clip_Lim[6]

Byte 12

Cust_ID0[7:0]

Byte 13

Cust_ID1[7:0]

Byte 14

Cust_ID2[7:0]

Byte 15

Signature[7:0]

Byte 16

A2D_Offset[0]

1V_Trim[3:0] **

Osc_Trim[2:0] **

Byte 17

JFET_cfg[0]

Update_Rate[1:0]

Output Select[1:0]

A2D_Offset[3:1]

Byte 18

Gain_B[6:0]

JFET_cfg[1]

Byte 19

Gain_B[14:7]

Byte 20

A5HEX

* SOT_cfg/Pamp_Gain

** 1V_Trim/JFET_Trim
