FT221X USB 8-BIT SPI/FT1248 IC Datasheet

Version 1.3

Document No.: FT_000630 Clearance No.: FTDI# 263

Appendix C - Revision History

Document Title:

USB 8-Bit SPI/FT1248 IC FT221X

Document Reference No.:

FT_000630

Clearance No.:

FTDI# 263

Product Page:

http://www.ftdichip.com/FT-X.htm

Document Feedback:

Send Feedback

Version 1.0

Initial Release

8th February 2012

Version 1.1

Added USB compliance in section 1.3

17th April 2012

Clarified MTP Reliability in table 6.8

Edited EEPROM Table 9.1 changed

Load VCP

Driver to Disabled and edited Product Description

Version 1.2

Removed references to LED signals on the CBUS pins as

14th Feb 2013

these are not available on the FT221X.

Removed section 8.2 showing connection of the Tx/Rx LEDs.

Updated TID

Updated US address

Added clarification on front page – 5V tolerant

Version 1.3

Removed references to MTP programming over FT1248 and

10th Feb 2014

clarified package dimensions.
