FT230XQ-R Datasheet(PDF) 17 Page - Future Technology Devices International Ltd. |
|
|
|||||||||||||||||||||||||||||
FT230XQ-R Datasheet(HTML) 17 Page - Future Technology Devices International Ltd. |
|
|
17 / 44 page  Copyright © Future Technology Devices International Limited 17 FT230X USB TO BASIC UART IC Version 1.4 Document No.: FT_000566 Clearance No.: FTDI# 260 5.3 DC Characteristics DC Characteristics (Ambient Temperature = -40°C to +85°C) Parameter Description Minimum Typical Maximum Units Conditions VCC VCC Operating Supply Voltage 2.97 5 5.5 V Normal Operation VCC2 VCCIO Operating Supply Voltage 1.62 --- 3.63 V Icc1 Operating Supply Current 6.5 8 8.3 mA Normal Operation Icc2 Operating Supply Current 125 μA USB Suspend 3V3 3.3v regulator output 2.97 3.3 3.63 V VCC must be greater than 3V3 otherwise 3V3OUT is an input which must be driven with 3.3V Table 5.3 Operating Voltage and Current |
|
