FEATURES

Dimensions in inches and (millimeters)

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

Rating at 25℃ ambient temperature unless otherwise specified.

Resistive or inductive load 60Hz.

For capacitive load current by 20%

CHARACTERISTICS

SYMBOL SQL9-1

SQL9-2

SQL9-3

SQL9-4

SQL9-6

SQL9-8 SQL9-10

UNIT

Maximum Recurrent Peak Reverse Voltage

100

200

300

400

600

800

1000

V

Maximum RMS Voltage

70

140

210

280

420

560

700

V

Maximum DC Blocking Voltage

100

200

300

400

600

800

1000

V

Maximum Average Forward

Rectified Current

Peak Forward Surage Current

8.3ms Single Half Sine-Wave

Super Imposed on Rated Load(JEDEC Method)

Peak Forward Voltage at 5.0A DC

V

Maximum DC Reverse Current

at Rated DC Blocking Voltage

Operating Temperature Range

℃

Storage Temperature Range

℃

1.2

μA

10

-40 to +130

-40 to +130

500

Rev. 7, 16-Mar-2017

5.0

A

150

A

SQL9-1 thru SQL9-10

THREE PHASE BRIDGE RECTIFIERS

REVERSE VOLTAGE - 100 to 1000Volts

FORWARD CURRENT -

5.0

Amperes

SQL

.228(5.8)

.244(6.2)

.110(2.8)

.126(3.2)

.236(6.0)

.276(7.0)

1.024(26.0)

1.083(27.5)

.484(12.3)

.524(13.3)

.028(0.7)

.035(0.9)

2.382(60.5)

2.343(59.5)

1.398(35.5)

1.437(36.5)

.906(23.0)

.866(22.0)

1.240(31.5)

1.280(32.5)
