ODiSI 6100

ODiSI 6100 Preliminary Data Sheet

ODiSI 6100 BASE CONFIGURATION

Additional Base

Configuration Features:

Included with Base Configuration:

•

ODiSI 6100 mainframe configured with 1 to 8

active measurement channels

•

ODiSI laptop controller laptop running single

function Linux OS and ODiSI operating software

and associated cabling

•

One 50m, rugged stand-off cable per channel

to connect ODiSI interrogator and one “remote

module” per channel which connects ODiSI

sensors to the stand-off cable

•

Standard configuration also includes a rugged

shipping case, sample fiber sensors (HD) and

Luna’s fiber optic sensor application kit

Real-time streaming data

•

Stream measurements in real-time

at the maximum measurement rate

to a file or via TCP-IP to another

computer

Ease of Integration / Ease of Use

•

Intuitive , easy to setup and use

graphical user interface

•

IEEE 1588 PTP (Precision Time

Protocol) synchronization

•

Json-based digital streaming data

•

Sync output TTL pulse

Reliability

•

Continuous automatic optical

alignment without user intervention

•

System and sensor health check

ensures high data fidelity

Traceability

•

Optical frequencies validated

every acquisition for accurate

measurements

•

Strain sensors and associated

coefficients calibrated with NIST

traceable fixtures

ODiSI 6100 Graphical User Interface
