Configuration

• SMC Plug Connector

• MIL-STD-348A

• 50 Ohms

• Right Angle Body Geometry

• RG58, RG303, RG141, PE-C195, PE-P195, LMR-

195, 0.195 inch Interface Type

• Crimp/Solder Attachment

• 1/4 inch Hex

Features

• Gold Plated Beryllium Copper Contact

• 30 µin minimum contact plating

Applications

• General Purpose Test

• Custom Cable Assemblies

.

Description

Pasternack’s PE4557 SMC plug right angle connector with crimp/solder attachment for RG58, RG303, RG141, PE-C195, PE-

P195, LMR-195 and 0.195 inch is part of our full line of RF components available for same-day shipping. Its right angle body

geometry allows for easier connections in tight spaces.

Our SMC plug right angle connector PE4557 datasheet specifications and drawing with dimensions are shown below in

this PDF. Pasternack’s broad catalog of RF, microwave and millimeter wave connectors allows designers to configure and

customize their signal connections however they like. Whether the need is to provide an I/O for a board design, or simply

create a custom cable assembly configuration, Pasternack has the right connector for the job. Pasternack can also expertly

build your custom cable assemblies for you and ship same-day.

Mechanical Specifications

Size

Length

0.62 in [15.75 mm]

Width/Dia.

0.315 in [8.00 mm]

Height

0.81 in [20.57 mm]

.

Weight

0.015 lbs [6.8 g]

.

Mating Torque

3 to 5 in-lbs [0.34 to 0.57 Nm]

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: SMC Plug Right Angle Connector Crimp/Solder Attachment for RG58, RG303, RG141, PE-

C195, PE-P195, LMR-195, 0.195 inch PE4557

PE4557 REV 1.1

SMC Plug Right Angle Connector Crimp/Solder Attachment for

RG58, RG303, RG141, PE-C195, PE-P195, LMR-195, 0.195 inch

RF Connectors Technical Data Sheet

PE4557
