V680 Series
16
Communication Specifications
ID Controllers (V680-CA5D01-V2/V680-CA5D02-V2)
RF Tag (1-kbyte Memory) Communication
*1. When using the V680-D1KP52MT/-D1KP53M embedded in metal, use the V680-HS51/-HS52 Antenna. Communications will not be possible with a V680-HS63
Antenna.
*2. The Antenna can be mounted in metal, but the communications distance will decrease compared to mounting in nonmetal.
Confirm performance using the actual devices before actual operation.
Recommended combination
Function
Communication
range
(unit: mm)
RF Tag and Antenna mounting conditions
RF Tag
Antenna
V680-D1KP52MT
V680-HS51
Read
distance
0.5 to 6.5
(axis offset ±2)
Write
distance
0.5 to 6.0
(axis offset ±2)
V680-HS52
Read
distance
0 to 9.0
(axis offset ±2)
Write
distance
0 to 8.5
(axis offset ±2)
V680-HS63
Read
distance
0 to 12.0
(axis offset ±2)
Write
distance
0 to 9.5
(axis offset ±2)
V680-D1KP52MT
(embedded in metallic
surface: steel)
V680-HS51
Read
distance
0.5 to 3.5
*1
(axis offset ±2)
Write
distance
0.5 to 3.0
*1
(axis offset ±2)
V680-HS52
Read
distance
0 to 4.5
*1
(axis offset ±2)
Write
distance
0 to 4.0
*1
(axis offset ±2)
V680-D1KP53M
V680-HS51
Read
distance
0.5 to 6.5
(axis offset ±2)
Write
distance
0.5 to 6.0
(axis offset ±2)
V680-HS52
Read
distance
0 to 9.0
(axis offset ±2)
Write
distance
0 to 8.5
(axis offset ±2)
V680-D1KP53M
(embedded in metallic
surface : steel)
V680-HS51
Read
distance
0.5 to 3.5
*1
(axis offset ±2)
Write
distance
0.5 to 3.0
*1
(axis offset ±2)
V680-HS52
Read
distance
0 to 4.5
*1
(axis offset ±2)
Write
distance
0 to 4.0
*1
(axis offset ±2)
V680-D1KP52MT
V680-HS51
Metallic
Non-metallic
Resin,
plastic,
wood, etc.
V680-D1KP52MT
V680-HS52
Non-metallic
Non-metallic
Resin,
plastic,
wood, etc.
*2
Non-metallic
V680-HS63
V680-
D1KP52MT
Non-metallic
Resin,
plastic,
wood, etc.
*2
Metallic
V680-D1KP52MT
Metallic
V680-HS51
V680-D1KP52MT
Metallic
V680-HS52
Non-metallic
*2
V680-D1KP53M
V680-HS51
Metallic
Non-metallic
Resin,
plastic,
wood, etc.
V680-D1KP53M
V680-HS52
Non-metallic
Non-metallic
Resin,
plastic,
wood, etc.
*2
Metallic
V680-D1KP53M
Metallic
V680-HS51
V680-D1KP53M
Metallic
V680-HS52
Non-metallic
*2
