background image
V680 Series
28
RF Tag (8-kbyte Memory) Communication
Recommended combination
Function
Communication
range
(unit: mm)
RF Tag and Antenna mounting conditions
RF Tag
Reader Writer
V680S-D8KF67
V680-HS52
Read
distance
1.0 to 17.0
(axis offset ±2)
Write
distance
1.0 to 17.0
(axis offset ±2)
V680-HS63
Read
distance
7.0 to 30.0
(axis offset ±10)
Write
distance
7.0 to 30.0
(axis offset ±10)
V680-HS65
Read
distance
5.0 to 42.0
(axis offset ±10)
Write
distance
5.0 to 42.0
(axis offset ±10)
V680S-D8KF67M
(flush-mounted on metallic
surface: steel)
V680-HS52
Read
distance
1.0 to 16.0
(axis offset ±2)
Write
distance
1.0 to 16.0
(axis offset ±2)
V680-HS63
Read
distance
6.0 to 25.0
(axis offset ±10)
Write
distance
6.0 to 25.0
(axis offset ±10)
V680-HS65
Read
distance
5.0 to 25.0
(axis offset ±10)
Write
distance
5.0 to 25.0
(axis offset ±10)
V680S-D8KF68
V680-HS63
Read
distance
5.0 to 45.0
(axis offset ±10)
Write
distance
5.0 to 45.0
(axis offset ±10)
V680-HS65
Read
distance
5.0 to 75.0
(axis offset ±10)
Write
distance
5.0 to 75.0
(axis offset ±10)
V680-
HS52
V680S-D8KF67
Non-metallic
Resin,
plastic,
wood, etc.
Non-metallic
V680-HS63
V680S-
D8KF67
Non-metallic
Resin,
plastic,
wood, etc.
Non-metallic
V680-HS65
V680S-D8KF67
Non-metallic
Resin,
plastic,
wood, etc.
Metallic
V680-
HS52
V680S-D8KF67M
Non-metallic
Metallic
V680-HS65
V680S-
D8KF67M
Non-metallic
Metallic
V680-HS65
V680S-
D8KF67M
Metallic
Metallic
V680-HS63
V680S-D8KF68
Non-metallic
Resin,
plastic,
wood, etc.
Non-metallic
Resin,
plastic,
wood, etc.
V680S-
D8KF68
V680-HS65
Non-metallic
Resin,
plastic,
wood, etc.
Metallic
