UNI SONI C TECHNOLOGI ES CO., LTD

LV321

LINEAR INTEGRATED CIRCUIT

www.unisonic.com.tw

1of 10

Copyright © 2018 Unisonic Technologies Co., Ltd

QW-R105-036.E

SI N GLE GEN ERAL PU RPOSE,

LOW V OLT AGE, RAI L-T O-RAI L

OU T PU T OPERAT I ON AL

AM PLI FI ER



DESCRI PT I ON

The UTC LV321 is a single op amp with low supply current. It

brings good

performance in low voltage, low power operating

systems. The UTC LV321 has a guaranteed 0.8V/µs slew rate and a

1MHz unity-gain bandwidth, in low supply current. It provides heavy

rail-to-rail (R-to-R) output swing loads and the input common-mode

voltage range including ground. Besides, it is also capable for

comfortably driving large capacitive loads.

The UTC LV321 has bipolar input and CMOS output for

improved noise performance and higher output current drive. It’s the

most cost effective solution for the applications where low voltage

operation, space saving and low price are required.



FEAT U RES

* 2.7V and 5V Performance Guaranteed

* No Crossover Distortion

* 130µA Low Supply Current

* Rail-to-Rail Output Swing @10k

V

 ORDERING INFORMATION

Ordering Number

Lead Free

Halogen Free

Package

Packing

LV321L-AF5-R

LV321G-AF5-R

SOT-25

Tape Reel

LV321L-AF5-A-R

LV321G-AF5-A-R

SOT-25

Tape Reel

LV321L-AL5-R

LV321G-AL5-R

SOT-353

Tape Reel
