IP5322 Datasheet(PDF) 4 Page - Injoinic Technology Co.,Ltd.

Part # IP5322
Description  Mobile power SOC with integrated input and output fast charge function
PDF  23 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
Manufacturer  INJOINIC [Injoinic Technology Co.,Ltd.]
Direct Link  http://www.injoinic.com
Logo INJOINIC - Injoinic Technology Co.,Ltd.

IP5322 Datasheet(HTML) 4 Page - Injoinic Technology Co.,Ltd.

  IP5322 Datasheet HTML 1Page - Injoinic Technology Co.,Ltd. IP5322 Datasheet HTML 2Page - Injoinic Technology Co.,Ltd. IP5322 Datasheet HTML 3Page - Injoinic Technology Co.,Ltd. IP5322 Datasheet HTML 4Page - Injoinic Technology Co.,Ltd. IP5322 Datasheet HTML 5Page - Injoinic Technology Co.,Ltd. IP5322 Datasheet HTML 6Page - Injoinic Technology Co.,Ltd. IP5322 Datasheet HTML 7Page - Injoinic Technology Co.,Ltd. IP5322 Datasheet HTML 8Page - Injoinic Technology Co.,Ltd. IP5322 Datasheet HTML 9Page - Injoinic Technology Co.,Ltd. Next Button
Zoom Inzoom in Zoom Outzoom out
 4 / 23 page
background image
IP5322
V1.02
Email: service@injoinic.com
4 / 23
Copyright © 2015, Injoinic Corp.
25
VIN
VIN 充电电源检测引脚
26
VING
VIN 充电输入 PMOS 控制引脚
27
VOUT2
VOUT2 放电负载智能检测引脚
28
VOUT2G
VOUT2 放电输出 NMOS 控制引脚
29
VOUT1G
VOUT1 放电输出 NMOS 控制引脚
30
VOUT1
VOUT1 放电负载智能检测引脚
31
DMA1
VOUT1 口手机快充智能识别 DM
32
DPA1
VOUT1 口手机快充智能识别 DP
33(EPAD)
GND
功率地和散热地，需要保持与 GND 良好接触
