FP1108R1-R18-R Datasheet(PDF) 1 Page - Eaton All Rights Reserved. |
|
|
|||||||||||||||||||||||||||||
FP1108R1-R18-R Datasheet(HTML) 1 Page - Eaton All Rights Reserved. |
|
|
1 / 4 page  Technical Data 10227 Effective September 2017 Supersedes April 2014 Product features • 11.0 mm x 8.0 mm x 7.5 mm surface mount package • Ferrite core material • Tight tolerance DCR for sensing circuits • Inductance range from 100 nH to 210 nH • Current range from 55 A to 100+ A Applications • Storage temperature range (component): -40 °C to +125 °C • Operating temperature range: -40 °C to +125 °C (ambient plus self-temperature rise) • Solder reflow temperature: J-STD-020 (latest revision) compliant FP1108R High frequency, high current power inductors Pb HALOGEN HF FREE • Multi-phase regulators • Voltage Regulator Modules (VRMs) • Desktop and server VRMs and EVRDs • Notebook and laptop regulators • Data networking and storage systems • Graphics cards and battery power systems • Point-of-Load modules • DCR Sensing circuits Environmental data |
