HCP0605-R10-R Datasheet(PDF) 1 Page - Eaton All Rights Reserved. |
|
|
|||||||||||||||||||||||||||||
HCP0605-R10-R Datasheet(HTML) 1 Page - Eaton All Rights Reserved. |
|
|
1 / 4 page  Technical Data 4368 Effective May 2017 Supersedes June 2009 Product features • High current carrying capacity, high permeability • Magnetically shielded, low EMI • Frequency range up to 1 MHz • 5.3 mm x 6.1 mm footprint surface mount package in a 4.95 mm height • Iron powder core material • Halogen free, lead free, RoHS compliant Applications • Voltage Regulator Module (VRM) • Multi-phase regulators • Desktop and server VRMs and EVRDs • Point-of-load (POL) modules • Notebook regulators • Data networking and storage systems • Graphics cards • Battery power systems Environmental data • Storage temperature range (component): -40 °C to +125 °C • Operating temperature range: -40 °C to +125 °C (ambient plus self-temperature rise) • Solder reflow temperature: J-STD-020 (latest revision) compliant HCP0605 High current power inductors Pb HALOGEN HF FREE Surface Mount Device |
