3 / 4 page  3 Technical Data 4368 Effective May 2017 HCP0605 High current power inductors www.eaton.com/electronics Temperature rise vs. total loss Core loss vs Bp-p Inductance characteristics % of O C L v s IDC 100% 90% 80% 70% 60% 50% 40% 30% 20% 10% 0% 0 5 10 15 20 25 30 35 D C I (Am p s) 80 70 60 50 40 30 20 10 0 0 0.3 0.6 0.9 1.2 1.5 1.8 T otal Loss (W ) 1000 1M Hz 100 500kHz 300kHz 200kHz 10 100kHz 1 0.1 0.01 0.001 0.0001 0.00001 10 100 1000 10000 Bp-p(G auss) |
|
|
