15-21/GHC-R2S2/2T
Everlight Electronics Co., Ltd.
http://www.everlight.com
Rev
1
Page: 3 of 10
Device No:DSE-0003945
Prepared date: 22-July-2010
Prepared by:Yang yuanyuan
Absolute Maximum Ratings (Ta=25℃)
Parameter
Symbol
Rating
Unit
Reverse Voltage
VR
5
V
Forward Current
IF
25
mA
Peak Forward Current
(Duty 1/10 @1KHz)
IFP
100
mA
Power Dissipation
Pd
95
mW
Electrostatic Discharge
ESD
150
V
Operating Temperature
Topr
-40 ~ +85
℃
Storage Temperature
Tstg
-40~ +90
℃
Soldering Temperature
Tsol
Reflow Soldering : 260℃ for 10sec.
Hand Soldering : 350℃ for 3 sec.
Electro-Optical Characteristics (Ta=25℃)
Parameter
Symbol
Min.
Typ.
Max.
Unit
Condition
Luminous Intensity
Iv
140
-----
285
mcd
Viewing Angle
2θ1/2
-----
130
-----
deg
Peak Wavelength
λp
-----
518
-----
nm
Dominant Wavelength
λd
-----
525
-----
nm
Spectrum Radiation
Bandwidth
λ
△
-----
35
-----
nm
Forward Voltage
VF
2.7
3.3
3.7
V
IF=20mA
Reverse Current
IR
-----
-----
50
µA
VR=5V
Notes:
Tolerance of Luminous Intensity ±11%
