15-21/GHC-R2S2/2T

Everlight Electronics Co., Ltd.

http://www.everlight.com

Rev

Page: 8 of 10

Device No:DSE-0003945

Prepared date: 22-July-2010

Prepared by:Yang yuanyuan

Reliability Test Items And Conditions

The reliability of products shall be satisfied with items listed below.

Confidence level：90%

LTPD：10%

No.

Items

Test Condition

Test

Hours/Cycles

Sample

Size

Ac/Re

Reflow Soldering

Temp. : 260℃±5℃

5 sec.

6 Min.

22 Pcs.

0/1

Temperature Cycle

H : +100℃ 15min

∫

5 min

L : -40℃ 15min

300 Cycles 22 PCS. 0/1

Thermal Shock

H : +100℃ 5min

∫

10 sec

L : -10℃ 5min

300 Cycles 22 PCS. 0/1

High Temperature

Storage

Temp. : 100℃

1000 Hrs. 22 PCS. 0/1

Low Temperature

Storage

Temp. : -40℃

1000 Hrs. 22 PCS.

0/1

DC Operating Life

IF = 20 mA

1000 Hrs. 22 PCS.

0/1

High Temperature /

High Humidity

85℃/85% RH

1000 Hrs. 22 PCS.

0/1
