IS25LP064A/032A

Integrated Silicon Solution, Inc.- www.issi.com

Rev. A

11/06/2015

9. ELECTRICAL CHARACTERISTICS

9.1 ABSOLUTE MAXIMUM RATINGS

(1)

Storage Temperature

-65°C to +150°C

Surface Mount Lead Soldering Temperature

Standard Package

240°C 3 Seconds

Lead-free Package

260°C 3 Seconds

Input Voltage with Respect to Ground on All Pins

-0.5V to VCC + 0.5V

All Output Voltage with Respect to Ground

-0.5V to VCC + 0.5V

VCC

-0.5V to +6.0V

Electrostatic Discharge Voltage (Human Body Model)

(2)

-2000V to +2000V

Notes:

Applied conditions greater than those listed in “Absolute Maximum Ratings” may cause permanent damage to

the device. This is a stress rating only and functional operation of the device at these or any other conditions

above those indicated in the operational sections of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect reliability.

2. ANSI/ESDA/JEDEC JS-001

9.2 OPERATING RANGE

Part Number

IS25LP064A/032A

Operating Temperature (Extended Grade E)

-40°C to 105°C

Operating Temperature (Extended+ Grade E1)

-40°C to 125°C

Operating Temperature (Automotive Grade A1)

-40°C to 85°C

Operating Temperature (Automotive Grade A2)

-40°C to 105°C

Operating Temperature (Automotive Grade A3)

-40°C to 125°C

VCC Power Supply

2.7V (VMIN)

– 3.6V (VMAX); 3.0V (Typ), Max. 133MHz

2.3V (VMIN)

– 3.6V (VMAX); 3.0V (Typ), Max. 104MHz
