ø30 ø30 Series Accessories and Replacement Parts

Maintenance Parts

Shape

Description

Material

Part No.

Ordering No.

Package

Quantity

Remarks

Button

For ø40 pushlock

turn reset

pushbuttons

(for AVN3)

AS resin AVN3B-➁

AVN3B-➁

R (red), Y (yellow)

Lens

For ø40 pushlock

turn reset

pushbuttons

(for AVLN3,

AVLNE3)

AS resin

AVLN3L-R

AVLN3L-RPN02

Red only

Lens

For ø40 pushlock

turn reset

pushbuttons

(for AJN3)

AS resin AJN3B-➁

AJN3B-➁

B (black), G (green),

R (red), Y (yellow)

Lens

For ø40 pushlock

turn reset

pushbuttons

(for AJLN3)

AS resin AJLN3L-➁

AJLN3L-➁

-G (green),

-R (red), L-Y (yellow),

L-A (amber), L-W (white)

Marking Plate

For UPQN4

Plastic

UPQN406N-W UPQN406N-WPN05

Rubber Washer (3.0mm thick)

Rubber

OW-12

OW-12PN10

Rubber Washer (1.5mm thick)

Rubber

OW-11

OW-11PN10

Shroud

➊

➋

➌

➍

➎

➏

➐

➊

Half shroud

(for pushbuttons)

Metal

ABN2G

➋

Full shroud

(for pushbuttons)

ABN2F

➌

Full shroud

(for mushroom

pushbuttons)

ABN3G

➍

Shallow shroud

(for jumbo mush-

rooms)

ABN4G

➎

Deep shroud

(for jumbo mush-

rooms)

ABN4F

➏

Half shroud

(for illuminated

pushbuttons)

ALN1GL

•For incandescent/LED

illuminated pushbuttons

(E12 base)

ALN2GL

•For LED illuminated

pushbuttons (BA9S base)

➐

Full shroud

(for illuminated

pushbuttons)

ALN1F

•For incandescent/LED

illuminated pushbuttons

(E12 base)

ALN2FL

•For LED illuminated push-

buttons (BA9S base)

Selector Knob

Knob for

Illuminated

selector switch

AS resin

ASLNH

ASLNH-∗

G (green), R (red),

S (blue)

ASLNHD

ASLNHD-∗

A (amber), W (white),

Y (yellow)

(14/03/18)
