MODEL: M8XT3

M8XT3 SPECIFICATIONS

ES-5385 Rev.5 Page 1/5

http://www.m-system.co.jp/

Dual Output Super-mini Signal Conditioners Pico-M Series

THERMOCOUPLE CONVERTER

(PC programmable, CE)

Functions & Features

• Converts a wide variety of thermocouple input into two

isolated, linearized process signals

• PC programmable

• Cold junction compensation

• Linearization

• Burnout protection

• User's temperature table can be used

• Space-saving, easy-to-maintain, multi-channel installation

base

MODEL: M8XT3-[1][2]-R[3]

ORDERING INFORMATION

• Code number: M8XT3-[1][2]-R[3]

Specify a code from below for each of [1] through [3].

(e.g. M8XT3-2V2V2-R/Q)

• Input range (e.g. 0 – 800°C)

• Output 1 / Output 2 (e.g. 1 – 5 V / 1 – 5 V DC)

K thermocouple setting will be used if the input code is not

specified. If no I/O specifications are specified, model M8XT3

-2V2V2-R/Q will be shipped.

For the input suffix code 0, use Ordering Information Sheet

(No. ESU-5470).

• Specify the specification for option code /Q

(e.g. /C01)

[1] INPUT THERMOCOUPLE

1: (PR) (Usable Range 0 to 1760°C, 32 to 3200°F)

2: K (CA) (Usable range -270 to +1370°C, -454 to +2498°F)

3: E (CRC) (Usable range -270 to +1000°C, -454 to +1832°F)

4: J (IC) (Usable range -210 to +1200°C, -346 to +2192°F)

5: T (CC) (Usable range -270 to +400°C, -454 to +752°F)

6: B (RH) (Usable range 0 to 1820°C, 32 to 3308°F)

7: R (Usable range -50 to +1760°C, -58 to +3200°F)

8: S (Usable range -50 to +1760°C, -58 to +3200°F)

9: C (WRe 5-26) (Usable range 0 to 2315°C, 32 to 4199°F)

N: N (Usable range -270 to +1300°C, -454 to +2372°F)

U: U (Usable Range -200 to +400°C, -328 to +752°F)

L: L (Usable Range -200 to +900°C, -328 to +1652°F)

P: P (Platinel II) (Usable Range 0 to 1395°C, 32 to 2543°F)

0: Specify

(Configurator software is used to change the input type and

range.)

[2] OUTPUT 1 / OUTPUT 2

V2Z1: Range -10 – +10 V DC / Range 0 – 20 mA DC

V2V2: Range -10 – +10 V DC / Range -10 – +10 V DC

(Configurator software is used to change output over the

described range of the selected suffix code.

For changing between suffix codes, set the Output Range

Selector on the side of unit before software adjustment.)

POWER INPUT

DC Power

R: 24 V DC

(Operational voltage range 24 V ±10 %, ripple 10 %p-p max.)

[3] OPTIONS

blank: none

/Q: With options (specify the specification)

SPECIFICATIONS OF OPTION: Q

COATING (For the detail, refer to M-System's web site.)

/C01: Silicone coating

/C02: Polyurethane coating

/C03: Rubber coating

RELATED PRODUCTS

• Installation Base or Single Mount Base Socket (model:

M8BSx)

This unit must be mounted on dedicated base or socket

except Model M8BS-1-1 socket.

• PC configurator software (model: JXCON)

Downloadable at M-System’s web site.

A dedicated cable is required to connect the module to the

PC. Please refer to the internet software download site or

the users manual for the PC configurator for applicable

cable types.

GENERAL SPECIFICATIONS

Construction: Plug-in

Mounting screw: M3 screw (torque 0.3 N·m)

Housing material: Flame-resistant resin (black)

Power supply: Via the Installation Base terminals

(model: M8BSx)

Isolation: Input to output 1 to output 2 to power

Overrange output: Approx. -15 to +115 %

Manual zero adjustments: -5 to +5 %
