MODEL: R7HL

R7HL SPECIFICATIONS

ES-7812 Rev.18 Page 49/55

http://www.m-system.co.jp/

Detecting Circuit

GND

LCH/RST

Detecting Circuit

Control

Circuit

Comm.

Circuit

Input

Circuit

24V DC

TXD– (NC)

TXD+ (NC)

RXD– (TR–)

RXD+ (TR+)

A–

A+

Z–

Z+

B–

B+ 5

+24V

GND

LCH

+24V 9

GND

OCA

GND

RST 13

GND

OCB

+24V

GND

■ R7HL-PA2SJ/C (RS-422 input, sensor excitation available)

+24V

GND

LATCH

ENCODER

ENCODER EXCITATION (OUT) 24V DC*

RESET

OPEN COLL. OUTPUT A

OPEN COLL. OUTPUT B

+24V

GND

+24V

GND

+24V

CH0

Input

Circuit

A–

A+

Z–

Z+

B–

B+ 5

+24V

GND

LCH

+24V 9

GND

OCA

GND

RST 13

GND

OCB

+24V

GND

+24V

GND

LATCH

ENCODER

RESET

OPEN COLL. OUTPUT A

OPEN COLL. OUTPUT B

+24V

GND

CH1

■ 2-Wire Sensor (LATCH/RESET)

Isolation

+24V

GND

+24V

GND

ENCODER EXCITATION (OUT) 24V DC*

*In case that the encoder’s excitation is not 24V DC, prepare an applicable voltage power supply unit.

Note 1: Terminal numbers in parentheses are for half-duplex communication model.

Note 2: For encoder input, use shielded twisted pair cable and the shield line must be grounded.
