MODEL: R7HL

R7HL SPECIFICATIONS

ES-7812 Rev.18 Page 3/55

http://www.m-system.co.jp/

EXTERNAL VIEW

■ View of R7HL-DAC16ES

X10

STATION ADD.

1 2 3 4 5 6 7 8

Station Address Setting Rotary SW

Status Indicator LED

Operating Mode Setting DIP SW (SW1)

Terminating Resistor SW

I/O Terminals

Network

Terminals

Power Supply Terminals

RUN

PWR

0 1 2 3 4 5 6 7 0 1 2 3 4 5 6 7

Discrete I/O Status Indicator LED

11 12 13 14

16 17 18 19 20

■ FRONT VIEW

■ SIDE VIEW

89A

■ View of R7HL-PA4E

X10

STATION ADD.

1 2 3 4 5 6 7 8

Station Address Setting Rotary SW

Status Indicator LED

Operating Mode Setting DIP SW (SW1)

Terminating Resistor SW

Input Connector

Network

Terminals

Power Supply Connector

RUN

PWR

0 1 2 3

Input Status Indicator LED

■ FRONT VIEW

■ SIDE VIEW

89A

CH0

SNSR EXC

PWR

CH1

CH2

CH3

Sensor Excitation Connector
