MODEL: R7HL

R7HL SPECIFICATIONS

ES-7812 Rev.18 Page 10/55

http://www.m-system.co.jp/

ADD.n

The data is 12-bit binary.

Divided by 8 times scan, 8 points input data is transferred by using CH designation bit.

CH0 – 7

Analog input data

CH designation of

analog input data

CH designation of

analog input data

Unused

• Di

■ ANALOG INPUT (R7HL-SVF8NL)

• Do

■ ANALOG OUTPUT (EXCEPT R7HL-YV4L) *1

CH0

Unused

CH1

• Di

• Do

ADD.n

(ADD.n)

CH0

CH1

ADD.n+2

(ADD.n+1)

The data is 16-bit binary.

Negative value is represented in 2’s complements.

Address in parentheses are for half-duplex mode.

*1. Scaling is available with Configurator Software (model: R7CON).

Refer to the Configurator Software users manual for detail.

ADD.n

CH0 – 3

Analog output data

CH designation of

analog output data

Unused

Analog output data

CH designation of

analog output data

Unused

• Di

■ ANALOG OUTPUT (R7HL-YV4L)

• Do

The data is 12-bit binary.

Divided by 4 times scan, 4 points output data is transferred by using CH designation bit.

For Di, the data written to Do is echoed back.
