background image
ADMV8432
Data Sheet
Rev. A | Page 4 of 17
Parameter
Min
Typ
Max
Unit
Test Conditions/Comments
DYNAMIC PERFORMANCE
Input IP3
34
dBm
Input Power at 5° Shift in Insertion Phase
20
dBm
VTUNE = 0 V
Group Delay Flatness
0.15
ns
VTUNE = 0 V
Phase Sensitivity
0.8
Rad/V
Amplitude Settling
200
ns
Time to settle to minimum insertion loss,
within ≤0.5 dB of static insertion loss
Drift Rate
−1.4
MHz/°C
Tuning Sensitivity
530
MHz/V
RESIDUAL PHASE NOISE
1 MHz Offset
−163
dBc/Hz
DC CHARACTERISTICS
Table 3.
Parameter
Min
Typ
Max
Unit
Test Conditions/Comments
fCENTER TUNING
Voltage (VTUNE)
0
15
V
Current (ITUNE)
±1
µA
BAND CONTROL VOLTAGE (VCTL)
Input Voltage
Low
0
0.8
V
0 V for high band select
High
2
2.5
3
V
2.5 V for low band select
Current
1
µA
SUPPLY VOLTAGES
Negative (VEE)
−5.5
−5
V
Positive (VDD)
5
5.5
V
SUPPLY CURRENTS
Negative (IEE)
0.7
mA
Positive (IDD)
1
mA
