USB7206C/KDX Datasheet(PDF) 18 Page - Microchip Technology |
|
|
|||||||||||||||||||||||||||||
USB7206C/KDX Datasheet(HTML) 18 Page - Microchip Technology |
|
|
18 / 56 page  2021 Microchip Technology Inc. DS00003850A-page 18 USB7206C Note 3-1 The default function is not used in the USB7206C. TABLE 3-5: PF[31:3] FUNCTION ASSIGNMENT Pin Configuration 3 PF3 I2S_SDI PF4 I2S_SDO PF5 I2S_SCK PF6 I2S_LRCK PF7 I2S_MCLK PF8 NC PF9 NC PF10 PRT_CTL3_U3 PF11 PRT_CTL4_U3 PF12 PRT_CTL5_U3 PF13 PRT_CTL5 PF14 PRT_CTL4 PF15 PRT_CTL3 PF16 PRT_CTL2 PF17 PRT_CTL1 PF18 MSTR_I2C_CLK PF19 MIC_DET PF20 SPI_CE_N PF21 SPI_CLK PF22 SPI_D0 PF23 SPI_D1 PF24 SPI_D2 PF25 SPI_D3 PF26 SLV_I2C_CLK PF27 SLV_I2C_DATA PF28 PRT_CTL6 PF29 (Note 3-1) PF30 VBUS_DET PF31 MSTR_I2C_DATA Note: The default PFx pin functions can be overridden with additional configuration by modification of the pin mux registers. These changes can be made during the SMBus configuration stage, by programming to OTP memory, or during runtime (after hub has attached and enumerated) by register writes via the SMBus slave interface or USB commands to the internal Hub Feature Controller Device. |
|
