2021 Microchip Technology Inc.

DS00003850A-page 29

USB7206C

6.0

DEVICE CONFIGURATION

The device supports a large number of features (some mutually exclusive), and must be configured in order to correctly

function when attached to a USB host controller. Microchip provides a comprehensive software programming tool,

MPLAB Connect Configurator (formerly ProTouch2), for OTP configuration of various USB7206C functions and regis-

ters. All configuration is to be performed via the MPLAB Connect Configurator programming tool. For additional infor-

mation on this tool, refer to the MPLAB Connect Configurator programming tool product page at http://

www.microchip.com/design-centers/usb/mplab-connect-configurator.

Additional information on configuring the USB7206C is also provided in the “Configuration of the USB720x/USB725x”

application note, which contains details on the hub operational mode, SOC configuration stage, OTP configuration, USB

configuration, and configuration register definitions. This application note, along with additional USB7206C resources,

can be found on the Microchip USB7206C product page at www.microchip.com/USB7206C.

Note:

Device configuration straps and programmable pins are detailed in Section 3.3, Configuration Straps and

Programmable Functions.

Refer to Section 7.0, Device Interfaces for detailed information on each device interface.
