 13 / 36 page
background image
ASIX ELECTRONICS CORPORATION
13
CONFIDENTIAL
AX88872P Swipeater Controller
PRELIMINARY
2.6 Buffer memory pins group
Signal Name
Type Pin No.
Description
BMA[16:0]
O
197-201
16,17
170,166
143,142
23-18
SSRAM Address Bus
BMD[31:24]
BMD[23:16]
BMD[15:8]
BMD[7:0]
I/O
24, 26-32
133-138
140, 141
171-173
175-179
180,
188-194
SSRAM Data Bus
/BMWE
O
158
SSRAM Write Strobe
/BMOE
O
159
SSRAM Read Strobe
BMCLK
O
72
SSRAM CLOCK
