5 / 22 page ![]() Data Sheet ADP1763 SPECIFICATIONS analog.com Rev. E | 5 of 22 INPUT AND OUTPUT CAPACITOR: RECOMMENDED SPECIFICATIONS Table 2. Parameter Symbol Test Conditions/Comments Min Typ Max Unit CAPACITANCE1 TA = −40°C to +125°C Input CIN 7.0 10 µF Output COUT 7.0 10 µF Regulator CREG 0.7 1 µF Reference CREF 0.7 1 µF CAPACITOR EQUIVALENT SERIES RESISTANCE (ESR) RESR TA = −40°C to +125°C CIN, COUT 0.001 0.5 Ω CREG, CREF 0.001 0.2 Ω 1 The minimum input and output capacitance must be >7.0 µF over the full range of the operating conditions. Consider the full range of the operating conditions in the application during device selection to ensure that the minimum capacitance specification is met. X7R and X5R type capacitors are recommended. Y5V and Z5U capacitors are not recommended for use with any LDO. |
|
|
