23 / 41 page

LUXEON K2 Datasheet DS51 (7/07)

Typical Forward Current Characteristics

CoolWhite, NeutralWhite, WarmWhite, Green, Cyan, Blue

and Royal Blue, Junction Temperature, TJ = 25°C

Red, RedOrange and Amber, Junction Temperature, TJ = 25°C

Notes for Figures 14 & 15:

Driving these high power devices at currents less than the test conditions (350 mA or 1000 mA) may produce unpre

dictable results and may be subject to variation in performance. Pulse width modulation (PWM) is recommended for

dimming effects.

100

200

300

400

500

600

700

800

900

1000

1100

1200

1300

1400

1500

1600

3.1

3.2

3.3

3.4

3.5

3.6

3.7

3.8

3.9

Vf - Forward Voltage (Volts)

Figure 14. Forward current vs. forward voltage for white, green, cyan, blue and royal blue.

-100

100

200

300

400

500

600

700

800

2.0

2.2

2.4

2.6

2.8

3.0

3.2

3.4

3.6

3.8

VF - Forward Voltage (Volts)

Figure 15. Forward current vs. forward voltage for red, redorange and amber.
