Rectifiers Diode

STPR820D

www.iscsemi.com

2

ELECTRICAL CHARACTERISTICS(TJ = 25°C unless otherwise specified)

SYMBOL

PARAMETER

CONDITIONS

MIN

MAX

UNIT

VF

Forward voltage

IF= 8A

--

1.1

V

IR

Reverse leakage current

Rate DC Voltage

--

10

uA

PACKAGE OUTLINE

Dimensions in mm
