STPR820D Datasheet(PDF) 1 Page - Inchange Semiconductor Company Limited |
|
|
|||||||||||||||||||||||||||||
STPR820D Datasheet(HTML) 1 Page - Inchange Semiconductor Company Limited |
|
|
1 / 2 page  Rectifiers Diode STPR820D www.iscsemi.com 1 FEATURES · Power Factor Correction function · Low reverse leakage current · High surge capacity APPLICATIONS · PFC circuits · solar inverters · UPS systems ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL PARAMETER VALUE UNIT VRRM Maximum Recurrent Peak Reverse Voltage 200 V VRMS Maximum RMS Voltage 140 V VDC Maximum DC Blocking Voltage 200 V IF(AV) Maximum Average Forward Rectified Current,TC=100℃ 8 A IFSM Peak Forward Surge Current 8.3ms Single Half Sine Wave Superimposed on Rated Load (Jedec Method) 90 A TJ junction temperature 150 ℃ Tstg storage temperature -55~150 ℃ THERMAL CHARACTERISTICS SYMBOL PARAMETER MAX UNIT Rth j-c Thermal resistance, junction-to-case 3.0 ℃ /W |
