OSMH50830GP-R5M3Z2C1P-A Datasheet(PDF) 2 Page - OptoSupply International

Part # OSMH50830GP-R5M3Z2C1P-A
Description  LED Light Strip
PDF  3 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
Manufacturer  OPTOSUPPLY [OptoSupply International]
Direct Link  http://www.optosupply.com
Logo OPTOSUPPLY - OptoSupply International

OSMH50830GP-R5M3Z2C1P-A Datasheet(HTML) 2 Page - OptoSupply International

  OSMH50830GP-R5M3Z2C1P-A Datasheet HTML 1Page - OptoSupply International OSMH50830GP-R5M3Z2C1P-A Datasheet HTML 2Page - OptoSupply International OSMH50830GP-R5M3Z2C1P-A Datasheet HTML 3Page - OptoSupply International
Zoom Inzoom in Zoom Outzoom out
 2 / 3 page
background image
Model No.
OSMW02C04GX-
XXX3ZXXXP-A
REV.
C2
Device Selection Guide
1
Module No.
Color
Dom. Wavelength
(Typ.)
Luminous Flux
(Typ.)
R5M3Z2C1P-X
Red
625±5nm
13.6lm
Y5M3Z2C1P-X
Yellow
590±5nm
11.6lm
G5D3Z2C1P-X
Green
527±5nm
18.4lm
B5S3Z2C1P-X
Blue
472±5nm
8.8lm
O5M3Z2C1P-X
Orange
605±5nm
12.5lm
M5S3Z2C1P-X
Warm White
X=0.45 ; Y=0.41
21.6lm
W5S3Z2C1P-X
White
X=0.27 ; Y=0.28
32.5lm
Absolute Maximum Ratings(Ta=25℃)
1
Items
Symbol
Values
Units
Operating supply range(DC/AC)
Vidc
14
V
Input Current (DC/AC)
Ii
120
MA
Power Dissipation
Pa
1.68
W
LED Light Source Temperature
Tled
105
DegC
Operating Temperature
Tope
-10 ~ +40
DegC
Storage Temperature
Tsto
-20 ~ +80
DegC
Typical Performance (Ta=25℃)
1
Items
Symbol
Min.
Typ.
Max.
Units
LED Module Power
Pm
---
0.96
1.68
w
Input Voltage(DC/AC)
Vi
12
14
V
Product input Current
If
80
120
mA
Beam Pattern
BP
---
120
---
Deg
Total diameter of PCB
DPCB.
---
22
---
mm
Net Weight
Wei.
---
3.5
---
g
2



Html Pages

1 2 3
