Model No.
OSMW02C04GX-
XXX3ZXXXP-A
REV.
C2
PRODUCT SPECIFICATION FOR LED Light Strip
Descriptions:
1
• Low Power Consumption, High Intensity
• Long life, Easy Installation
• Voltages Available 12VDC/AC
• LED Model Number: OSXXX3ZXXXP 1
Features:
1
• Available in Red , Orange , Yellow , Green , Blue , White
• Directly use on DC/AC
• Low Power Consumption , High intensity, Long life
• Excellent beam control, Energy saving
• Part number or the connection pin is JCG4,two type to choose
from the below: OSMW02C04GS is perpendicular and OSPM-
OSMW02C04GX is crooked
Application:
1
• Channel letter signs
• Indirect accent décor light
• Large area back lighting
• Under counter light
• Decorate building ’s contour
• Substitute neon light
Product Picture:
1
1
