Military ProASIC3/EL DC and Switching Characteristics

2-12

Revision 3

Table 2-14 • Summary of I/O Input Buffer Power (per pin) – Default I/O Software Settings

Applicable to Advanced I/O Banks for A3P250 and A3P1000 Only

VMV (V)

Static Power

PDC6 (mW)1

Dynamic Power

PAC9 (µW/MHz)2

Single-Ended

3.3 V LVTTL / 3.3 V LVCMOS

3.3

–

16.22

3.3 V LVCMOS – Wide Range

3.3

–

16.22

2.5 V LVCMOS

2.5

–

4.65

1.8 V LVCMOS

1.8

–

1.65

1.5 V LVCMOS (JESD8-11)

1.5

–

0.98

3.3 V PCI

3.3

–

17.64

3.3 V PCI-X

3.3

–

17.64

Differential

LVDS

2.5

2.26

0.83

LVPECL

3.3

5.72

1.81

Notes:

1. PDC6 is the static power (where applicable) measured on VMV.

2. PAC9 is the total dynamic power measured on VMV.

Table 2-15 • Summary of I/O Input Buffer Power (per pin) – Default I/O Software Settings

Applicable to Standard Plus I/O Banks for A3P250 and A3P1000 Only

VMV (V)

Static Power

PDC6 (mW) 1

Dynamic Power

PAC9 (µW/MHz) 2

Single-Ended

3.3 V LVTTL / 3.3 V LVCMOS

3.3

–

16.23

3.3 V LVCMOS – Wide Range

3.3

–

16.23

2.5 V LVCMOS

2.5

–

4.66

1.8 V LVCMOS

1.8

–

1.64

1.5 V LVCMOS (JESD8-11)

1.5

–

0.99

3.3 V PCI

3.3

–

17.64

3.3 V PCI-X

3.3

–

17.64

Notes:

1. PDC6 is the static power (where applicable) measured on VMV.

2. PAC9 is the total dynamic power measured on VMV.
