8 / 24 page  ADF4106 Data Sheet Rev. E | Page 8 of 24 TYPICAL PERFORMANCE CHARACTERISTICS FREQ MAGS11 ANGS11 0.500 0.89148 –17.2820 0.600 0.88133 – 20.6919 0.700 0.87152 – 24.5386 0.800 0.85855 –27.3228 0.900 0.84911 –31.0698 1.000 0.83512 – 34.8623 1.100 0.82374 –38.5574 1.200 0.80871 –41.9093 1.300 0.79176 – 45.6990 1.400 0.77205 –49.4185 1.500 0.75696 –52.8898 1.600 0.74234 –56.2923 1.700 0.72239 –60.2584 1.800 0.69419 –63.1446 1.900 0.67288 –65.6464 2.000 0.66227 –68.0742 2.100 0.64758 –71.3530 2.200 0.62454 –75.5658 2.300 0.59466 –79.6404 2.400 0.55932 –82.8246 2.500 0.52256 –85.2795 2.600 0.48754 –85.6298 2.700 0.46411 –86.1854 2.800 0.45776 –86.4997 2.900 0.44859 –88.8080 3.000 0.44588 –91.9737 3.100 0.43810 –95.4087 3.200 0.43269 –99.1282 FREQ MAGS11 ANGS11 3.300 0.42777 –102.748 3.400 0.42859 –107.167 3.500 0.43365 –111.883 3.600 0.43849 –117.548 3.700 0.44475 –123.856 3.800 0.44800 –130.399 3.900 0.45223 –136.744 4.000 0.45555 –142.766 4.100 0.45313 –149.269 4.200 0.45622 –154.884 4.300 0.45555 –159.680 4.400 0.46108 –164.916 4.500 0.45325 –168.452 4.600 0.45054 –173.462 4.700 0.45200 –176.697 4.800 0.45043 178.824 4.900 0.45282 174.947 5.000 0.44287 170.237 5.100 0.44909 166.617 5.200 0.44294 162.786 5.300 0.44558 158.766 5.400 0.45417 153.195 5.500 0.46038 147.721 5.600 0.47128 139.760 5.700 0.47439 132.657 5.800 0.48604 125.782 5.900 0.50637 121.110 6.000 0.52172 115.400 FREQ UNIT GHz KEYWORD R PARAM TYPE S IMPEDANCE 50 Ω DATA FORMAT MA Figure 5. S-Parameter Data for the RF Input 0 –30 –5 –10 –25 –20 –15 6 5 4 3 2 1 0 RF INPUT FREQUENCY (GHz) VDD = 3V VP = 3V TA = +85°C TA = –40°C TA = +25°C Figure 6. Input Sensitivity 0 –100 –90 –80 –70 –60 –50 –40 –30 –20 –10 –2kHz –1kHz 900MHz 1kHz 2kHz FREQUENCY VDD = 3V, VP = 5V ICP = 5mA PFD FREQUENCY = 200kHz LOOP BANDWIDTH = 20kHz RES BANDWIDTH = 10Hz VIDEO BANDWIDTH = 10Hz SWEEP = 1.9 SECONDS AVERAGES = 10 –93.0dBc/Hz REF LEVEL = –14.3dBm Figure 7. Phase Noise (900 MHz, 200 kHz, and 20 kHz) –40 –140 –130 –120 –110 –100 –90 –80 –70 –60 –50 100Hz 1MHz FREQUENCY OFFSET FROM 900MHz CARRIER 10dB/DIV RL = –40dBc/Hz RMS NOISE = 0.36 ° Figure 8. Integrated Phase Noise (900 MHz, 200 kHz, and 20 kHz) 0 –100 –90 –80 –70 –60 –50 –40 –30 –20 –10 –400kHz –200kHz 900MHz 200kHz 400kHz FREQUENCY REF LEVEL = –14.0dBm VDD = 3V, VP = 5V ICP = 5mA PFD FREQUENCY = 200kHz LOOP BANDWIDTH = 20kHz RES BANDWIDTH = 1kHz VIDEO BANDWIDTH = 1kHz SWEEP = 2.5 SECONDS AVERAGES = 30 –91.0dBc/Hz Figure 9. Reference Spurs (900 MHz, 200 kHz, and 20 kHz) –83.5dBc/Hz 0 –100 –90 –80 –70 –60 –50 –40 –30 –20 –10 –2kHz –1kHz 5800MHz 1kHz 2kHz FREQUENCY REF LEVEL = –10dBm VDD = 3V, VP = 5V ICP = 5mA PFD FREQUENCY = 1MHz LOOP BANDWIDTH = 100kHz RES BANDWIDTH = 10Hz VIDEO BANDWIDTH = 10Hz SWEEP = 1.9 SECONDS AVERAGES = 10 Figure 10. Phase Noise (5.8 GHz,1 MHz, and 100 kHz) |
|
|
