background image
INCHANGE Semiconductor
isc website：www.iscsemi.com
isc & iscsemi is registered trademark
2
isc Silicon NPN Darlington Power Transistor
2SD1481
ELECTRICAL CHARACTERISTICS
TC=25℃ unless otherwise specified
SYMBOL
PARAMETER
CONDITIONS
MIN
TYP.
MAX
UNIT
VCE(sat)*
Collector-Emitter Saturation Voltage
IC= 1A, IB= 1mA
1.5
V
VBE(sat)*
Base-Emitter Saturation Voltage
IC= 1A, IB= 1mA
2.0
V
ICBO
Collector Cutoff Current
VCB= 40V, IE= 0
1
uA
hFE-1*
DC Current Gain
IC= 1A; VCE= 2V
2000
20000
hFE-2*
DC Current Gain
IC= 3A; VCE= 2V
500
*:Pulse test PW≤350us,duty cycle≤2%
Switching Times
ton
Turn-on Time
IC= 1A; IB1= IB2= 1mA
0.5
μ
s
ts
Storage Time
2.0
μ
s
tf
Fall Time
1.0
μ
s
hFE-1 Classifications
M
L
K
2000-5000
4000-10000 8000-20000
