Humidity and Temperature

Sensor

Description

ChipCap 2-SIP by Telaire is a Single In-Line

Package type of ChipCap with ready installed

V-Core capacitor for easy and convenient

application.

ChipCap offers the most advanced and cost

effective humidity and temperature sensing solution

for virtually any type of applications. Capacitive

polymer sensor chip developed and fabricated in-

house and CMOS integrated circuit with EEPROM

are integrated into one embedded system.

Individually calibrated and tested, ChipCap 2-SIP

performs ±2% from 20% to 80%RH (±3% over

entire humidity range), and yet is simple and ready

to use without further calibration or temperature

compensation.

ChipCap 2-SIP offers another sensible sensing

solution for excellent reliability, high accuracy, and

cost effective sensing applications.

Features

• Fully Calibrated & Temperature Compensated

• Precision and Accuracy (±2%RH, ±0.3°C, 14 bit )

• Free Operating Voltage (min 2.3V to max 5.5V)

• Low Current Consumption

• SIP (Single-In-line-Package)

• Reliable in Harsh Environment

• Eliminates the reconditioning procedure needed

for surface mount RH sensors

• Field replaceable.

• Allows better air circulation and response time

Applications

• Energy Saving HVAC Control: Air Conditioning,

Refrigeration, IAQ monitoring, Vent Fans, Home

Appliances,Humi/Dehumidifiers

• Process Control and Instrumentation: Sensor

Performance

• Medical Instruments, Handheld Devices, Weather

Stations, Food Processing, Printers, RFIDs

• Automobile & Transportation Cabin Climate

Control, Defogging Control, Condensing

Preventive Devise

• Mass Quantity Application: OEM custom

specificationavailable
