background image
1.0 Signal/Pin Connection and Description (Continued)
32
www.national.com
1.5
INTERNAL PULL-UP AND PULL-DOWN RESISTORS
The signals listed in Table 4 can optionally support internal pull-up (PU) and/or pull-down (PD) resistors. See Section 14.3
for the values of each resistor type.
Table 4. Internal Pull-Up and Pull-Down Resistors
Signal
Pin/s
Type
Comments
ACCESS.bus (ACB)
SCL
54
PU25
Programmable
SDA
55
PU25
Programmable
Game Port (GMP)
JOYABTN0
119
PU25
Programmable
JOYABTN1
120
PU25
Programmable
JOYBBTN0
123
PU25
Programmable
JOYBBTN1
124
PU25
Programmable
General-Purpose Input/Output (GPIO) Ports
GPIO00-07
2-9
PU25
Programmable
GPIO10
GPIO11-14
GPO15
GPIO16-17
21
53-56
57
69, 71
PU25
Programmable
GPIO20-27
117-124
PU25
Programmable
GPIO30-33
GPIO34
125-128
1
PU25
Programmable
Keyboard and Mouse Controller (KBC)
P12, P16, P17
6,127,7
PU25
Musicial Instrument Digital Interface (MIDI) Port
MDRX
126
PU25
Programmable
Strap Configuration
BADDR
101
PD30
Strap
PSLDC0
99
PD30
Strap
PSLDC1
107
PD30
Strap
PSONPOL
109
PD30
Strap
TEST
98
PD30
Strap
Parallel Port
ACK
79
PU50
AFD_DSTRB
93
PU100
BUSY_WAIT
78
PD30
ERR
91
PU50
