3.0 System Wake-Up Control (SWC) (Continued)
93
www.national.com
3.4.7
Wake-Up Events Routing to SMI Enable Register 0 (WK_SMIEN0)
This register is set to 00h on power-up of VPP or software reset. It controls the routing of detected wake-up events to the
SMI signal. Detected wake-up events that are enabled activate the SMI signal regardless of the value of the WK_EN0 reg-
ister.
Location:
Bank 2, Offset 13h
Type:
R/W
Bit
76543210
Name
Reserved
Software
Event to
SMI Enable
Reserved
CEIR
Event to
SMI Enable
Mouse
Event to
SMI Enable
KBD
Event to
SMI Enable
RI2
Event to
SMI Enable
RI1
Event to
SMI Enable
Reset
00000000
Bit
Description
7
Reserved
6
Software Event to SMI Enable
0: Disabled (default)
1: Enabled
5
Reserved
4
CEIR Event to SMI Enable
0: Disabled (default)
1: Enabled
3
Mouse Event to SMI Enable
0: Disabled (default)
1: Enabled
2
KBD Event to SMI Enable
0: Disabled (default)
1: Enabled
1
RI2 Event to SMI Enable
0: Disabled (default)
1: Enabled
0
RI1 Event to SMI Enable
0: Disabled (default)
1: Enabled
